C# Buffer BlockCopy Example

Use methods on the Buffer type, including Buffer.BlockCopy and ByteLength.

Buffer. The Buffer type handles ranges of bytes. It includes the optimized Buffer.BlockCopy method. This copies a range of bytes from one array to another.Optimization Array

Buffer methods. The Buffer class also provides the ByteLength, GetByte and SetByte methods. Usually BlockCopy is the most interesting.

BlockCopy. To begin, Buffer.BlockCopy does not copy logical elements in arrays. Instead it copies bytes. We call it to copy the bytes in one byte array to another.

Note: This is useful for compression, images, or many other types of binary data.

Byte

Here: The ints are actually used as bytes, not 4-byte ints. The byte array arr2 is automatically initialized to all zero bytes.

Byte Array

C# program that uses BlockCopy on bytes using System; class Program { static void Main() { byte[] arr1 = new byte[] { 1, 2, 3, 4, 5 }; byte[] arr2 = new byte[10]; // Copy the first five bytes from arr1 to arr2 Buffer.BlockCopy(arr1, 0, arr2, 0, 5); Display(arr2); } static void Display(byte[] arr) { for (int i = 0; i < arr.Length; i++) { Console.Write(arr[i]); } Console.WriteLine(); } } Output 1234500000

Example 2. Buffer.BlockCopy can act on a data type that is not 1 byte. An int is 4 bytes. The fifth parameter of Buffer.BlockCopy is the number of bytes to copy.

Note: We need to pass in the number of bytes to copy, not the array element count. We must multiply it by 4, or the sizeof(int).

Note 2: In this example, the sizeof() operator returns the byte length of a primitive data type like int. Here it returns 4.

And: The multiplication of sizeof(int) * 4 can be resolved by the C# compiler—it won't cause any slowdowns.

C# program that copies ints using System; class Program { static void Main() { int[] arr1 = new int[] { 1, 2, 3, 4, 5 }; int[] arr2 = new int[10]; // Copy the first twenty bytes from arr1 to arr2 Buffer.BlockCopy(arr1, 0, arr2, 0, 5 * sizeof(int)); Display(arr2); } static void Display(int[] arr) { for (int i = 0; i < arr.Length; i++) { Console.Write(arr[i]); } Console.WriteLine(); } } Output 1234500000

ByteLength. ByteLength returns the byte count for an array. In this example there are 2 arrays—an integer array and a byte array—allocated on the managed heap.

Note: We use Buffer.ByteLength to count the total number of bytes in each array. Each int is 4 bytes. Each byte is a single byte.

C# program that uses Buffer.ByteLength method using System; class Program { static void Main() { // Example arrays for program. // ... Each array has three elements. int[] array1 = { 1, 2, 3 }; byte[] array2 = { 1, 2, 3 }; // Get lengths of arrays. // ... This counts the bytes in all elements. int length1 = Buffer.ByteLength(array1); int length2 = Buffer.ByteLength(array2); // Write results. Console.WriteLine(length1); Console.WriteLine(length2); } } Output 12 3

GetByte, SetByte. Next we use Buffer.GetByte and SetByte. We have an array of 3 integer values (an int array). Note that integers (int variables) in C# code are represented by 4 bytes.Int Array Int, uint

Note: By using GetByte and SetByte, we read and assign the individual bytes in each integer directly.

Tip: This changes the decimal representation of the integer by changing the bytes in the integer.

And: This is used to treat an integer array as a bitmask or other structure. One bit is used to indicate true or false.

True, False

C# program that uses Buffer.GetByte and Buffer.SetByte using System; class Program { static void Main() { // Use an array of three integers for testing. // ... Loop through the bytes in the array and write their values. int[] array1 = { 1, 1, 256 }; for (int i = 0; i < Buffer.ByteLength(array1); i++) { Console.WriteLine(Buffer.GetByte(array1, i)); } // Set certain byte values at indexes in the array. Buffer.SetByte(array1, 0, 55); Buffer.SetByte(array1, 4, 55); Buffer.SetByte(array1, 8, 55); // Render the modified array. Console.WriteLine("---"); for (int i = 0; i < Buffer.ByteLength(array1); i++) { Console.WriteLine(Buffer.GetByte(array1, i)); } } } Output 1 0 0 0 1 0 0 0 0 1 0 0 --- 55 0 0 0 55 0 0 0 55 1 0 0

Benchmark, BlockCopy. To test Buffer.BlockCopy further, I benchmarked it on a 1000-element array. I found it has a significant performance advantage over Array.Copy.

Version 1: This version of the code uses Buffer.BlockCopy on a 1000-element byte array. It tests the result for correctness.

Version 2: This version uses Array.Copy with similar arguments to the Buffer.BlockCopy version.

Result: Using Buffer.BlockCopy is consistently faster. For copying larger arrays of values, it should be preferred.

Also: Copying the elements in a for-loop was far slower. So using BlockCopy is a significant win.

Array.Copy For

C# program that benchmarks Buffer.BlockCopy using System; using System.Diagnostics; class Program { static byte[] GetSourceArray() { // Populate data. var result = new byte[1000]; result[0] = 100; result[999] = 1; return result; } static bool IsValidData(byte[] data) { // Test data. return data[0] == 100 && data[999] == 1; } const int _max = 10000000; static void Main() { const int size = 1000; byte[] source = GetSourceArray(); byte[] target = new byte[size]; // Version 1: use Buffer.BlockCopy. var s1 = Stopwatch.StartNew(); for (int i = 0; i < _max; i++) { Buffer.BlockCopy(source, 0, target, 0, size); if (!IsValidData(target)) { return; } } s1.Stop(); // Reset. source = GetSourceArray(); target = new byte[size]; // Version 2: use Array.Copy. var s2 = Stopwatch.StartNew(); for (int i = 0; i < _max; i++) { Array.Copy(source, target, size); if (!IsValidData(target)) { return; } } s2.Stop(); Console.WriteLine(((double)(s1.Elapsed.TotalMilliseconds * 1000000) / _max).ToString("0.00 ns")); Console.WriteLine(((double)(s2.Elapsed.TotalMilliseconds * 1000000) / _max).ToString("0.00 ns")); } } Output 33.75 ns Buffer.BlockCopy 51.65 ns Array.Copy

BitConverter. With this class we can change representations of value types. The BitConverter is sometimes used alongside Buffer.BlockCopy in programs that handle low-level data.BitConverter

A summary. The Buffer type contains low-level methods that act upon bytes. A buffer is a range of bytes. With BlockCopy, we optimize large array copies of value types.
